Guilin Microtech Optical Instrument Co., Ltd. (MTO)

Phone：+86-773-5823609

PRODUCT

Position：  > Product  >  Attachments  >  Stereo Microscopes Attachments  > Stands
Stands

Note：
There are more than 10 kinds of stands which are with or not with illuminations can be selected. The microscopes' standard outfits stand of with built-in coaxial illumination is SD11, of not with built-in coaxial illumination is SD1.

Model：SD1 Stand

Introduction：
·Not with illuminator, the diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm

SD1


Model：SD2 Stand

Introduction：
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separable power line.
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD2


Model：SD3 Stand

Introduction：
·Not with illuminator, the range of the square post adjusting focus is 100mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD3


Model：SD4 Stand

Introduction：
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separablepower line.
·The measurement to match between the support and the main body is Φ76mm.
·The range of the square post adjusting focus is 100mm.
·The diameter of the center working stage is Φ95mm.

SD4


Model：SD5 Stand

Introduction：
·Not with illuminator, the diameter of the round post is Φ25mm, the height is 240mm
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm

SD5


Model：SD6 Stand

Introduction：
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separablepower line.
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD6



Model：SD7 Stand

Introduction：
·Not with illuminator, the range of the square post adjusting focus is 100mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.


SD7


Model：SD8 Stand

Introduction：
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separablepower line.
·The measurement to match between the support and the main body is Φ76mm.
·The range of the square post adjusting focus is 100mm.
·The diameter of the center working stage is Φ95mm.

SD8


Model：SD9 Stand

Introduction：
·Big soleplate of polymethyl methacrylate
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.

SD9


Model：SD10 Stand

Introduction：
·Big black anticorrosive soleplate, the size is 400×300×20mm.
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.

SD10



Model：SD11 Stand

Introduction：
·Black painting steel soleplate. And SD11 is steady.
·It can fix S7650 mechanical stage directly.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm


Model：SD12 Stand

Introduction：
·The special stand of coaxial illumination, the axes of the fixing main body hole and the stand woking stage is strictly vertical.
·The range of the square post adjusting focus is 100mm.
·The measurement to match between the support and the main body is Φ76mm.

SD12


Model：SD1J Stand

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD1J


Model：SD2J Stand

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separablepower line.
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD2J


Model：SD3J Stand

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·Not with illuminator, the range of the square post adjusting focus is 100mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm.

SD3J


Model：SD4J Stand

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·In holder with adjusting angles and lighteness, 6V/10W, the reflected illumination of the halogen lamp.
·In Stand with 110V or 220V/5W the transmitted illumination of the fluorescent lamp.
·The up and down illuminators can use singly or simultaneity. Selected kinds of separable power line.
·The measurement to match between the support and the main body is Φ76mm.
·The range of the square post adjusting focus is 100mm.
·The diameter of the center working stage is Φ95mm.

SD4J


Model：   SD17 Round post sector Up and Down LED illumination Stands

Introduction：
·In holder with adjusting angles and lighteness, the reflected illumination of white LED.
·In stands with the transmitted illumination of white LED.
·The up and down illuminators can use singly or synchronously.
·The input voltage of wide range: AC90V~260V   47~63Hz
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm. Match with a black-white workbench and a transparent glass workbench

SD17


Model：  SD18 Square post sector Up and Down LED illumination Stands

Introduction：
·In holder with adjusting angles and lighteness, the reflected illumination of white LED.
·In stands with the transmitted illumination of white LED.
·The up and down illuminators can use singly or synchronously.
·The input voltage of wide range: AC90V~260V   47~63Hz
·The range of the square post adjusting focus is 80mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm. Match with a black-white workbench and a transparent glass workbench.

SD18

Model：   SD17J Round post sector Up and Down LED illumination Stands(With fine adjustment)

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·In holder with adjusting angles and lighteness, the reflected illumination of white LED.
·In stands with the transmitted illumination of white LED.
·The up and down illuminators can use singly or synchronously.
·The input voltage of wide range: AC90V~260V   47~63Hz
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm. Match with a black-white workbench and a transparent glass workbench.


Model：  SD18J Square post sector Up and Down LED illumination Stands(With fine adjustment)

Introduction：
·Glancing inching coaxial handwheel, can adjust the tension of glancing adjusting handwheel.
·In holder with adjusting angles and lighteness, the reflected illumination of white LED.
·In stands with the transmitted illumination of white LED.
·The up and down illuminators can use singly or synchronously.
·The input voltage of wide range: AC90V~260V   47~63Hz
·The range of the square post adjusting focus is 80mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm. Match with a black-white workbench and a transparent glass workbench.

SD18J


Model：   SD2/3W Round post sector Up and Down 3W LED illumination Stands

Introduction：
·In holder with adjusting angles and lighteness, the reflected illumination of white 3W LED.
·In stands with the transmitted illumination of white 3W LED.
·The up and down illuminators can use singly or synchronously.
·The input voltage of wide range: AC90V~260V   50/60Hz
·The diameter of the round post is Φ25mm, the height is 240mm.
·The range of holders adjusting focus is 50mm.
·The measurement to match between the support and the main body is Φ76mm.
·The diameter of the center working stage is Φ95mm. Match with a black-white workbench and a transparent glass workbench

SD2/3W
